SAE 100R3

SAE 100R3 OIL RESISTANT RUBBER HOSE

Applications:Suitable for conveying petroleum-based hydraulic oil, lubricating oil, gasoline, fuel oil, water and air, etc

Tube:Black oil-resistant synthetic rubber
Reinforcement:Two layers of woven fiber
Cover:Black oil-resistant, weather-resistant, wear-resistant synthetic rubber
Temperature Range:-40 °C to + 100℃ (-40°F to + 212°F)

Request A Quote

Product Application

Applications:Suitable for conveying petroleum-based hydraulic oil, lubricating oil, gasoline, fuel oil, water and air, etc

Product Attributes

Tube:Black oil-resistant synthetic rubber
Reinforcement:Two layers of woven fiber
Cover:Black oil-resistant, weather-resistant, wear-resistant synthetic rubber
Temperature Range:-40 °C to + 100℃ (-40°F to + 212°F)

Product Parameters

SIZE(Dash) SIZE(in.)   I.D.(mm) O.D.(mm) Max.W.P. Min.B.P.. MinB.R..
Min Max Max (MPa) (MPa) (mm)
3 3/16 4.5 5.4 13.5 10.5 42 75
4 1/4 6.1 7 15.1 8.7 34.8 75
5 5/16 7.6 8.5 18.3 8.4 33.6 100
6 3/8 9.2 10.1 19.8 7.8 31.2 100
8 1/2 12.4 13.5 24.6 7 28 125
10 5/8 15.6 16.7 27.8 6.1 24.4 140
12 3/4 18.7 19.8 32.5 5.2 20.8 150
16 1 25.1 26.2 39.3 3.9 15.6 205
20 1 1/4 31.4 32.9 46 2.6 10.4 250
